196W COB Highy Bay Light IP65 with Genesis or Bridgelux Chip from China manufacturer

196W COB Highy Bay Light IP65 with Genesis or Bridgelux Chip

Price:	200.0~240.0 USD
Payment Terms:	T/T,L/C,WU
Place of Origin:	Zhejiang, China (Mainland)


	Add to My Favorites
HiSupplier Escrow	Share \|

Product Detail

Model No.: HL-HB-196W

Production Capacity: 100,000pcs per month

Delivery Date: Within 30 days after deposi...

Power: 196W

LED Qty: 1pc

Means of Transport: Ocean,Air

Packing: Each pc in blister packing ...

Voltage: DC30-36V

LED Chip Type: Genesis, Bridgelux

IP Rating: IP65

1. DC30-36V
2. COB Chip
3. IP65

Item No. : HL-HB-196W
Name : Excellent Dissipation 196W COB Highy Bay Light IP65 with Genesis or Bridgelux Chip

Technique Data of China 196W COB Highy Bay Light IP65 with Genesis or Bridgelux Chip:

Model number HL-HB-196W color rendering index WW:Ra>68,PW/CW:Ra>75
LED consumptions 196W beam angle 90/45/120
System Consumption 210W working voltage DC30-36V
Led initial flux WW PW CW input voltage AC85-265V
18900LM 18960LM 18935LM
power factor >0.98 frequency range 50-60HZ
total hamornical distortion <9% led junction temperature <80°C
power efficiency >82% working temperature -25~45°C
light efficiency >91% IP grade IP65
installation height 6M 8M 10M led working life-span >50000hrs
average illuminance 110.1LUX 53LUX 29LUX certification CE ROHS
illuminance area φ9.5M φ15.5M φ19M Item dimension D525*416mm
illminance uniformity >0.4 net weight/gross weight 16KGS
Chip Brand Genesis's LED chip (2Years Warranty) Bridgelux LED chip (3Years Warranty)

Advantage of Excellent Dissipation 196W COB Highy Bay Light IP65 with Genesis or Bridgelux Chip:

This light has been applied a new heat-removal system, compared with the traditional cooling system, our new cooling system add heat transfer oil which can help the system remove heat from the whole light more quickly and efficiently.
